Probability | Binomial Distribution | Dominant Traits 🧬

Question:

• Suppose that a particular trait of a person is classified on the basis of one pair of genes and suppose that d represents a dominant gene and r a recessive gene.
• Thus, a person with dd genes is pure dominance, one with rr is pure recessive, and one with rd is hybrid.
• There is no outwardly difference between the appearances of hybrid or pure dominant.
• If, with respect to a particular trait, two hybrid parents have a total of four children, what is the probability that exactly three of the four children have the outward appearance of the dominant gene?

Step 01: Creation of the variables

    Module[{parent1 = Style["dr", 12, Red], parent2 = Style["rr", 12, Darker@Green]}, {parent1, parent2}]


Step 02: Possible Children

Since both of the parents are mixed, any of the child born to this set of parents would receive either “r” or “d” from either of the parents. The types of children possible from this union are as follows.

    Module[{parent1 = Style["d", 12, Red], parent2 = Style["r", 12, Darker@Green], children},
        children = Tuples[{parent1, parent2}, 2];
        Table[Apply[StringJoin, ToString[#, StandardForm] & /@ children[[r]]], {r, 1, Length@children}]]

Amongst the progeny, the children “dd”, “dr”, “rd” would be outwardly display the dominant characteristics. This is \(\frac{3}{4}\).

Step 03: Numerical Solution

According to the question, we need to find the probability that 3 out of 4 children would have the outward appearance of the dominant gene. This is a binomial type problem and below is the numerical answer. \[{4\choose 3} {\frac{3}{4}}^{3} {(1-\frac{3}{4})}^{1} = \frac{27}{64} \approx 0.421875 \]

Step 04: Simulation

We can also do a simulation of the same to see how the probabilities match up to the results calculated numerically.

    ClearAll[childrenColor, progeny];
    (*This function colors the string. This function has not been used here by the way*)
    childrenColor[child_String] := Module[{list = StringSplit[child, ""]},
      Table[If[list[[r]] == "r", Style["r", Darker@Green], Style["d", 12, Red]], {r, 1, Length@list}]]

    (*This function simulates the progeny given a number*)
    progeny[number_] :=
     Module[{parent1 = "d", parent2 = "r", children, barData},
      children = StringJoin @@@ RandomChoice[{parent1, parent2}, {number, 2}];
      barData = Transpose[{Length[#], #[[1]]} & /@ Gather@children];
      BarChart[barData[[1]], ChartLabels -> barData[[2]], PlotLabel -> ToString[number] <> " children"]]

    GraphicsGrid[Partition[progeny[#] & /@ {25, 100, 200, 500, 1000, 5000, 10000, 20000, 50000}, 3], ImageSize -> 700]


You can see that the proportions (and the probabilities) match up at high numbers with the ratio being roughly \(\frac{1}{4}\).
If only 4 children are allowed, then the probability of 3 of four children having an outwardly appearance of the dominant gene is \(\frac{27}{64} \approx 0.421875\) according to our calculation earlier. This is seen below. Notice that we are repeating the allowed trials. For example, the first chart in the set has a number 10 under it. This means that this is a distribution of probability of 3 dominant children in a population where 10 paris of parents are allowed to have 4 children each. Observe how the distribution gets narrower with larger population.

    (*Modified function for this part*)
    progeny[number_] := Module[{parent1 = "d", parent2 = "r", children, barData},
    children =StringJoin @@@ RandomChoice[{parent1, parent2}, {number, 2}]]

    exactly3Dominant[trials_] :=
        Module[{three = Length@Cases[Length[Cases[#, "dd" | "dr" | "rd"]] & /@ Table[progeny[4], trials], 3]}, three/trials]

    Module[{trials = {10, 25, 50, 100, 200, 300, 500, 750, 1000, 2000, 5000, 10000}},
        DistributionChart[Table[exactly3Dominant[#], 100] & /@ trials,
            ChartElementFunction -> "HistogramDensity",
            ImageSize -> 700,
            PlotLabel -> "Distribution of fixed trials repeated 100 times.",
            ChartLabels -> trials,
            AxesLabel -> {"Trials", "Probability"}]
        ]
